Exhibit library
Exhibits
Every exhibit makes one point, carries its unit and its source, and can be checked on its own. The exhibits below use illustrative data.
-
In this illustrative line, adherence to standard work falls to 71% by Q4 after retraining
Share of observed tasks done to the written standard, one line, by quarter after the last retraining, %
Data: Share of observed tasks done to the written standard, one line, by quarter after the last retraining, % Category Value Q1 92% Q2 84% Q3 77% Q4 71% Note Values are placeholders chosen to demonstrate the exhibit format. Time runs left to right, so bars are not sorted by value.
Source Illustrative data; not a research finding
-
In this illustrative plant, the night shift confirms daily routines least often
Share of scheduled daily routines confirmed as completed, one month, by shift, %
Data: Share of scheduled daily routines confirmed as completed, one month, by shift, % Category Value Day 88% Swing 81% Night 63% Note Values are placeholders chosen to demonstrate the exhibit format. The plant’s stated standard is 95% (not shown as a bar).
Source Illustrative data; not a research finding
-
In this illustrative plant, shift-level self-checks confirm routines on 750 shifts a year
Shifts on which daily routines are confirmed in one year, one plant, three shifts a day, by method, shifts
Data: Shifts on which daily routines are confirmed in one year, one plant, three shifts a day, by method, shifts Category Value Shift-level self-check 750 shifts Weekly leadership walk 50 shifts Note Values are placeholders chosen to demonstrate the exhibit format. They describe no real plant. A monthly management review (12 shifts a year in this illustration) is not shown.
Source Illustrative data; not a research finding
-
In this illustrative plant, most management-system signals already exist in shift records
Number of distinct signals identified, one plant, by where the record is kept
Data: Number of distinct signals identified, one plant, by where the record is kept Category Value Shift handover notes 14 Tiered meeting boards 11 Maintenance work orders 9 Quality hold records 6 Monthly review packs 3 Note Values are placeholders chosen to demonstrate the exhibit format. They describe no real plant.
Source Illustrative data; not a research finding
